A powerhouse router designed for demanding home lab environments, equipped with USB 3.0, 1G and 2.5G Ethernet connectivity, and a high-speed 10G SFP+ interface. With an ultra-dense form factor that fits four routers into just 1U of rack space, it offers remarkable performance without sacrificing space efficiency.
RB5009UG+S+IN
Product Highlights:
-
64-BIT ARM CPU, 4 CORES / 4 THREADS, 350–1400 MHz
-
7 × 1G PORTS, 1 × 2.5G PORT, 1 × 10G SFP+ SLOT
-
COMPACT SIZE: 220 x 125 x 22 mm, 1U RACK-FRIENDLY
-
FLEXIBLE POWER: DC JACK, POE-IN, 2-PIN TERMINAL (24–57V)
-
1 GB RAM, 1 GB NAND STORAGE, USB 3.0 WITH POWER RESET
-
PASSIVE COOLING, CPU TEMPERATURE MONITORING, MTBF ~200,000 HRS
-
OPERATING TEMP: -40°C TO 60°C, CERTIFIED CE / EAC / ROHS
| Category | Specification |
|---|---|
| Product Code | RB5009UG+S+IN |
| Architecture | 64-bit ARM |
| CPU | 88F7040, 4 cores, 4 threads, 350–1400 MHz (auto) |
| Switch Chip | 88E6393 |
| Dimensions | 220 x 125 x 22 mm |
| Operating System | RouterOS v7, License Level 5 |
| RAM | 1 GB |
| Storage | 1 GB NAND |
| Reliability | MTBF ~200,000 hours at 25°C |
| Operating Temperature | -40°C to 60°C |
| Power Inputs | 3 (DC jack, PoE-IN, 2-pin terminal) |
| Input Voltage | 24–57 V (all DC inputs) |
| Max Power | 25 W (14 W without attachments) |
| PoE | 802.3af/at, 24–57 V |
| Cooling | Passive |
| Ethernet Ports | 7 × 1G, 1 × 2.5G |
| SFP+ | 1 slot |
| USB | 1 × USB 3.0 Type-A, 1.5 A, USB power reset supported |
| Other Features | CPU temperature monitoring |
| Certifications | CE, EAC, RoHS |
