Rujie/Reye RG-RAP2260(G)
Product Highlights:
| Highlights |
|---|
| High-performance Wi-Fi 6 (802.11ax) access point |
| Supports up to 512 users / 110 recommended users |
| Dual-band: 2.4 GHz & 5 GHz, throughput 2.97 Gbps |
| Built-in omnidirectional antennas for easy deployment |
| Maximum coverage up to 120 m² (≈1292 sq. ft.) |
| Efficient low power consumption (<18 W) |
| Ideal for offices, hotels, and enterprise environments |
The RG-RAP2260(G) is a ceiling-mount Wi-Fi 6 (802.11ax) dual-band access point delivering high-speed wireless performance up to ~1775 Mbps with support for both 2.4 GHz and 5 GHz connections. It efficiently handles a large number of clients with MU-MIMO and OFDMA technologies, and supports easy setup and cloud management via the Ruijie Cloud app.
| Category | Specification |
|---|---|
| Brand | Ruijie Reyee |
| Model | RG-RAP2260(G) |
| Wireless Protocol | 802.11ax (Wi-Fi 6), up to 2.97 Gbps |
| Antennas | Built-in Omni-directional |
| CPU | N/A |
| Throughput | 2.97 Gbps |
| MIMO | 2×2 @ 2.4 GHz, 2×2 @ 5 GHz |
| Max. WAN Ports | 1 × 100/1000/2500 Base-T, 1 × 10/100/1000 Base-T |
| Recommended Users | 512 / 110 |
| Power Supply | < 18 W |
| Frequency Bands | 2.4 GHz & 5 GHz |
| Maximum Coverage | Up to 120 m² (≈1292 sq. ft.) |
| Modulation | DSSS: DBPSK, DQPSK, CCK; OFDM/MIMO-OFDM: BPSK, QPSK, 16/64/256-QAM |
