TS-664
Product Highlights:
• CPU Intel® Celeron® N5095 4-core/4-thread processor, burst up to 2.9 GHz
• Graphic Processors: Intel® UHD Graphics
• CPU Architecture: 64-bit x86
• System Memory: 8 GB RAM
• Flash Memory: 4GB RAM
• 2.5GbE (2.5G/1G/100M) ports.
• Drive Bay: 6 x 3.5-inch SATA 6Gb/s
• Smooth video conversion
• Quad-core for multitasking
TS-664 is a compact 6-bay NAS with superior performance. Supporting up to 110 TB storage and 4 TB M.2 SSD caching* at an affordable price, the TS-664 fulfills your multitasking challenges for file management, backup, collaboration, and video conversion.
| Component | Specification |
|---|---|
| CPU | Intel® Celeron® N5095 4-core/4-thread processor, burst up to 2.9 GHz |
| CPU Architecture | 64-bit x86 |
| Graphic Processors | Intel® UHD Graphics |
| Floating Point Unit | ✅ |
| Encryption Engine | AES-NI |
| Hardware-accelerated Transcoding | ✅ |
| System Memory | 8 GB RAM |
| Maximum Memory | 8 GB |
| Flash Memory | 4GB (Dual boot OS protection) |
| Drive Bay | 6 x 3.5-inch SATA 6Gb/s |
| Drive Compatibility | 3.5-inch SATA hard disk drives, 2.5-inch SATA solid state drives |
| Hot-swappable | ✅ |
| M.2 Slot | 2 x M.2 2280 PCIe Gen 3 x1, Compatible with NVMe SSD PCIe Gen 3 and above |
| SSD Cache Acceleration Support | ✅ |
| 2.5 Gigabit Ethernet Port | 2 (2.5G/1G/100M/10M) |
| 5 Gigabit Ethernet Port | Optional via PCIe expansion card |
| 10 Gigabit Ethernet Port | Optional via PCIe expansion card |
| Wake on LAN (WOL) | ✅ |
| Jumbo Frame | ✅ |
| PCIe Slot | 1, PCIe Gen 3 x2 |
| USB 2.0 port | 2 |
| USB 3.2 Gen 2 (10Gbps) Port | 2 x Type-A |
| IR Sensor | Optional QNAP RM-IR004 remote control |
| HDMI™ Output | 1, HDMI™ 2.1 (up to 4096 x 2160 @ 60Hz) |
| Form Factor | Tower |
| LED Indicators | Power/Status, LAN, USB, HDD1-6 |
| Buttons | Power, USB copy, Reset |
| Dimensions (HxWxD) | 165 × 235 × 226.5 mm |
| Weight (Net) | 2.94 kg |
| Weight (Gross) | 5.1 kg |
| Operating Temperature | 0 ~ 40˚C (32˚F ~ 104˚F) |
| Storage Temperature | -20 – 70°C (-4°F – 158°F) |
| Relative Humidity | 5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F) |
| Power Supply Unit | 120W adapter, 100-240V |
| Power Consumption: HDD Sleep Mode | 23.22 W |
| Power Consumption: Operating Mode, Typical | 44.02 W |
| Fan | 2 x 90mm, 12VDC |
| System Warning | Buzzer |
| Kensington Security Slot | ✅ |
| Standard Warranty | 3 years |
| Max. Number of Concurrent Connections (CIFS) – with Max. Memory | 1,500 |
