TS-832PXU-RP

Product Highlights:

    • CPU: AnnapurnaLabs Alpine AL324 64-bit ARM® Cortex-A57 4-core 1.7GHz processor
    • Two 10GbE SFP+ and two 2.5GbE RJ45 network ports
    • System Memory: 4 GB UDIMM DDR4 (1 x 4 GB)
    • Redundant power supply
    • Flash Memory: 512 MB
    • Drive Bay: 8 x 3.5-inch SATA 6Gb/s, 3Gb/s
    • HBS (Hybrid Backup Sync)

Buy This Product
description Specifications

With 10GbE SFP+ and 2.5GbE network ports, the TS-832PXU-RP delivers high network bandwidth to streamline team collaboration and file access. A PCIe Gen 2 ×2 slot allows for installing a QNAP expansion card to add network connectivity, SSD caching capabilities, or wireless connectivity. The TS-832PXU-RP supports file backup and synchronization, secure snapshot protection, and Google™ Workspace and Microsoft 365® enterprise account backup services, while providing instant recovery whenever needed. Coupled with the support for cloud gateways, building a new hybrid cloud storage solution has never been easier. The TS-832PXU-RP also features a redundant power supply to ensure uninterrupted operation of mission-critical applications.

Component Specification
CPU AnnapurnaLabs Alpine AL324 64-bit ARM® Cortex-A57 4-core 1.7GHz processor
CPU Architecture 64-bit ARM
Floating Point Unit ✅
Encryption Engine ✅
System Memory 4 GB UDIMM DDR4 (1 x 4 GB)
Maximum Memory 16 GB (1 x 16 GB)
Memory Slot 1 x UDIMM DDR4
Flash Memory 512 MB (Dual boot OS protection)
Drive Bay 8 x 3.5-inch SATA 6Gb/s, 3Gb/s
Drive Compatibility
  • 3.5-inch SATA hard disk drives
  • 2.5-inch SATA hard disk drives
  • 2.5-inch SATA solid state drives
Hot-swappable ✅
M.2 Slot Optional via a PCIe adapter
SSD Cache Acceleration Support ✅
2.5 Gigabit Ethernet Port 2 (2.5G/1G/100M/10M)
10 Gigabit Ethernet Port 2 x 10GbE SFP+
Wake on LAN (WOL) ✅
Jumbo Frame ✅
PCIe Slot 1 (PCIe Gen 2 x2)
USB 3.2 Gen 1 port 4
Form Factor 2U Rackmount
LED Indicators HDD 1-8, Status, LAN, Storage expansion
Buttons Power, Reset
Dimensions (HxWxD) 88.6 × 432 × 511 mm
Weight (Net) 12.47 kg
Weight (Gross) 14.61 kg
Operating Temperature 0 – 40 °C (32°F – 104°F)
Storage Temperature -20 – 70°C (-4°F – 158°F)
Relative Humidity 5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F)
Power Supply Unit 250W (x2) PSU, 100 – 240V
Power Consumption (Operating Mode, Typical) 69.191 W
Fan 2 x 70mm, 12VDC
System Warning Buzzer
Standard Warranty 3 Years
Max. Number of Concurrent Connections (CIFS) – with Max. Memory 700
